Technical Specifications

• RJ-45 ports: 8x 10/100Base-TX ports, auto detection, auto MDI/MDI-X
• Standards: IEEE 802.3 10Base-T, IEEE 802.3u 100Base-TX
• Communication Distance: 100 mt communication distance
• Power Supply: 12-48VDC supply
• Housing: Metal body
• Mounting: DIN rail mount
• EMI: FCC Part 15 Subpart B classA EN55022 class A
• EMC Standards:
  • IEC(EN)61000-4-2(ESD)
  • IEC(EN)61000-4-3(RS)
  • IEC(EN)61000-4-4(EFT)
  • IEC(EN)61000-4-5(Surge)
  • IEC(EN)61000-4-6(CS)
  • IEC(EN)61000-4-8
• Environmental Tests:
  • IEC 60068-2-27(Shock)
  • IEC 60068-2-32(Freefall)
  • IEC 60068-2-6(Vibration)
• Certification: CE approved
