HPS-480 Güç Kaynağı
General Features
- Fixed Output Voltage
- Fixed Output Current
- Low Cost
- High Reliability
- Overload Protection
- Overvoltage Protection
- Short Circuit Protection
- 100% Full Load Test
- Rail Mounting
- LED Indicator for Power
- CE Approved according to EN Standards
- Voltage Range: 100 to 240 VAC, 90 to 350 VDC (allowed range: 85 to 264 VAC)*6
- AC Current: AC100-220V 5.2A / DC90-350V 2.8A
- Efficiency: 86%
- Inrush Current: 115VAC 16A / 230VAC 32A
- Leakage Current: <1mA/240VAC
- DC Voltage: 24VDC
- Rated Current: 20A
- Current Range: 0-20A
- Rated Power: 480W
- Ripple and Noise: 240Mv
- Voltage Adjustment Range: -10% to 15%
- Voltage Tolerance: ±1.0%
- Setup and Rise Time: 1000ms, 60ms at full load/230VAC 1800ms, 60ms/ 115VAC
- Hold Up Time: 115VAC 24ms / 230VAC 24ms
- Overload: 105% to 150% of rated load current
- High Voltage: 30-36V
- Vibration: Vibration values at 0.375 mm single amplitude for 2 hours in each of the X, Y, and Z directions at 10~55 Hz. 10 to 150 Hz, 0.35 mm single amplitude for 80 minutes in each of the X, Y, and Z directions (maximum 5 G for 60W, 120W, 240 W).
- Operating Temperature and Humidity Values: -10℃~+70℃; 20%~90%RH
- Storage Temperature and Humidity Values: -20℃~+85℃; 10%~95%RH
- Withstand Voltage: I/P-O/P: 3KVAC I/P-FG: 1.5KVAC O/P-FG: 0.5KVAC
- Isolation Resistance: I/P-O/P, I/P-FG, O/P-FG: 100M Ohms / 500VDC
- EMC Standard: EN55011,EN55022,EN61000-3-2,-3,EN61000-4- 2,3,4,5,6,8,11,ENV50204,EN55024,EN61000-6-2(EN50082-2)
- Width: 86 mm
- Height: 131 mm
- Depth: 138 mm
- Weight: 1300g
